Thermwood 5 Axis High-Performance Heavy-Duty Model 90 Videos

The Multi-Purpose 90 is a heavy-duty five-axis designed for high-speed trimming and pattern machining, available in single or dual moving aluminum tables.  It is capable of full five axis simultaneous motions with extremely fast accelerations.

Model 90 10'x5' Single Table

Model 90 5'x12' DualTable

---

Available Features:

• 12 HP 24,000 RPM Router with a 4 Position Automatic Tool Changing System (Standard)
• 16 HP 24,000 RPM Router with a 4 Position Bar Style Automatic Tool Changing System (Optional)
• 21.5 HP 24,000 RPM Router with a 4 Position Bar Style Automatic Tool Changing System (Optional)
• 1" Thick Solid Aluminum Vacuum Table (Standard)
• 1/2" Thick Multi-Function Vacuum Table (Optional)
• Extended Z Axis: 36" vertical (Optional)
• Extended Z Axis: 48" vertical (Optional)
• Extended Z Axis: 60" vertical (Optional)
• Six Position Tool Bar Under Gantry (Optional)
• Four Position Automatic Tool Changer - On Right Side Gantry Leg (Standard)
• Ten Position Rotary Automatic Tool Changer (Optional)
• Twelve Position Tool Bar (mounted to back of table) (Optional)
• Automatic Tool Length Measurement (Optional)
• Automatic Tool Length Sensor (Optional)
• Automatic Lubrication System (Optional
• Gantry Lighting System (Optional)
• Accu-Lube Mist Coolant System (Optional)
• Machine Enclosure (Optional)
• Impact Resistant Five Axis Head (Standard)
• Continuous C Axis (Optional)
• Three-Dimensional Laser Compensated Axis Alignment
• Siemens Intelligent Servo Drives Throughout
• QCore SuperControl
• Machine Training and Installation
• Free Lifetime Phone/Forum Support
